- Place of Origin: Shandong, China
- Brand Name: XINLONGHAO
- Model Number: SJZ6.0-1.7
- :
- :
- :
- :
- :
- :
Applications of the scissor lift table :
This stationary scissor lift platform Equipment is mainly used in loading cargo between vehical and cargo shelf in workshop or warehouse, no need to set us cargo table, steel shelf etc, it lifts from the ground level to load and discharge, professional designed movable extended board makes the connection more smooth between the table and vehicle so to make the operation of folklift, hydraulic hand pallet more easy, the table can be put into the foundation, after work, the table is on the same level with the ground, no space occupation, no affection to the traffic.
1) The stationary scissor lift platform is generally used for lifting cargo and people to working place .Loading and unloading goods from ground to underground or to other floors
2)It is characterized by great loading capacity.
3) Hydraulic lift system Steady ascending and descending
4)Electric or manual drive
5) The scissor lift is heavy-carrying
6) Lift tables are suitable for factory, institutions, shopping ,garages ,warehouse and other industries.
Safety Precaution of this scissor lift table :
1. Explosion-proof valves: protect hydraulic pipe, anti-hydraulic pipe rupture.
2. Spillover valve: It can prevent high pressure when the machine moves up. Adjust the pressure.
3. Emergency decline valve: it can go down when you meet an emergency or the power off.
- Place of Origin: Shandong, China
- Brand Name: XINLONGHAO
- Model Number: SJZ6.0-1.7
- :
- :
- :
- :
- :
- :
Specification | Vertical travel (mm) | Lowered Height (mm) | Capacity (mm) | Platform size (L*W, mm) | Power (Kw) |
SJZ1.0-1.6 | 1600 | 300 | 1000 | 2500*1500 | 1.5 |
SJZ1.5-1.6 | 1600 | 360 | 1500 | 2500*1500 | 2.2 |
SJZ2.0-1.6 | 1600 | 400 | 2000 | 2500*1600 | 2.2 |
SJZ3.0-1.6 | 1600 | 400 | 3000 | 2600*1800 | 3.0 |
SJZ5.0-1.6 | 1600 | 450 | 5000 | 2600*1800 | 4.0 |
SJZ6.0-1.7 | 1700 | 540 | 6000 | 2800*2000 | 5.5 |
SJZ9.0-1.8 | 1800 | 600 | 9000 | 3000*1800 | 5.5 |
